F110M-8 1" Throat Size HF Device
The next addition to the Eminence compression driver family. The F110M-8 offers all the performance benefits of our new ring radiator devices in a smaller format which performs remarkably well on screw on type horns or coaxial woofers.
Specifications
Download Spec Sheet| SPECIFICATION | |
| Throat Size | 1", 25.4mm |
| Nominal Impedance* | 8Ω |
| Minimum Impedance | 5.5 ohm @ 7.9 kHz |
| Power Rating** | 25 W (AES) |
| Resonance | 1.2kHz |
| Usable Frequency Range | 2000Hz-20kHz |
| Recommended Crossover | 2 kHz @ 12 dBkHz |
| Sensitivity*** | 108.4 |
| Magnet Material | Ferrite |
| Magnet Weight | 12oz, 0.34kg |
| Voice Coil Diameter | 1" / 25.4mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Mylar |
| DC Resistance (Re) | 4.5Ω |
| MOUNTING INFORMATION | |
| Overall Diameter | 3.35", 85mm |
| Driver Volume Displaced | 0.006 cu.ft., 0.18 liters |
| Depth | 2.83", 72mm |
| Weight | 1.71 lbs, 0.78 kg |
| Mounting Thread | 1 3/8 in. 18 ext |
| Mounting Holes Diameter | N/A |
| Mounting Holes B.C.D. | N/A |
Frequency Response
The next addition to the Eminence compression driver family. The F110M-8 offers all the performance benefits of our new ring radiator devices in a smaller format which performs remarkably well on screw on type horns or coaxial woofers.
Specifications
Download Spec Sheet| SPECIFICATION | |
| Throat Size | 1", 25.4mm |
| Nominal Impedance* | 8Ω |
| Minimum Impedance | 5.5 ohm @ 7.9 kHz |
| Power Rating** | 25 W (AES) |
| Resonance | 1.2kHz |
| Usable Frequency Range | 2000Hz-20kHz |
| Recommended Crossover | 2 kHz @ 12 dBkHz |
| Sensitivity*** | 108.4 |
| Magnet Material | Ferrite |
| Magnet Weight | 12oz, 0.34kg |
| Voice Coil Diameter | 1" / 25.4mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Mylar |
| DC Resistance (Re) | 4.5Ω |
| MOUNTING INFORMATION | |
| Overall Diameter | 3.35", 85mm |
| Driver Volume Displaced | 0.006 cu.ft., 0.18 liters |
| Depth | 2.83", 72mm |
| Weight | 1.71 lbs, 0.78 kg |
| Mounting Thread | 1 3/8 in. 18 ext |
| Mounting Holes Diameter | N/A |
| Mounting Holes B.C.D. | N/A |
Frequency Response
$16.10
Original: $45.99
-65%F110M-8 1" Throat Size HF Device—
$45.99
$16.10Description
